Juniper SRX300 Series Reference Guide

1-Port T1/E1 Mini-Physical Interface Module (SRX-MP-1T1E1-R) Network
Interface Specifications
The 1-Port T1/E1 Mini-Physical Interface Module (Mini-PIM) has the network interface specifications
given in Table 28 on page 50.
Table 28: 1-Port T1/E1 Mini-PIM (SRX-MP-1T1E1-R) Network Interface Specifications
E1 SpecificationsT1 SpecificationSpecification
Network interface specifications
2.048 Mbps1.544 MbpsTransmit bit rate
2.048 Mbps1.544 MbpsReceive bit rate
HDB3AMI/B8ZSLine encoding
Framed Clear Channel, Unframed
Clear Channel
Framed Clear ChannelMode
G704 without CRC4 UnframedSuperframe (D4/SF), Extended
Superframe (ESF)
Fractional Framing
HDLC features
(E1:N=1 to 31)(T1:N=1 to 24)N x 64 Kbps or N x 56 Kbps,
nonchannelized data rates
16/3216/32CRC
SupportedSupportedShared Flag
SupportedSupportedIdle flag/fill
Runts, Giants, FCS, Error, Abort Error,
Align Error
Runts, Giants, FCS, Error, Abort Error,
Align Error
Counters:
50

Juniper SRX300 Series Specifications

General

Memory	4 GB
CPU	Intel Atom
Storage	8 GB
Operating Temperature	32°F to 104°F (0°C to 40°C)
Humidity	10% to 90% noncondensing
