Juniper SRX300 Series Reference Guide

Table 13: 1-Port Serial Mini-PIM (SRX-MP-1SERIAL-R) Physical Specifications
ValueDescription
0.8 in. x 3.75 in. x 5.9 in.
(2.0 cm x 9.5 cm x 14.5 cm)
Dimensions (H x W x L)
3.04 oz (86 g)Weight
60-pin Synchronous Serial (female)Connector type
Mini-PIMForm factor
1-Port Serial Mini-Physical Interface Module (SRX-MP-1SERIAL-R) LEDs
The 1-Port Serial Mini-Physical Interface Module (Mini-PIM) has one LED located to the right of the serial
port. Table 14 on page 30 describes the LED states.
Table 14: 1-Port Serial Mini-PIM (SRX-MP-1SERIAL-R) LED States
DescriptionStateColorName
Online with no alarms or failures.OnGreenSTATUS
Device has detected a failure.Off
1-Port Serial Mini-Physical Interface Module Interface Cables
Table 15 on page 30 lists the cables that you can order from Juniper Networks to connect to a port on
the synchronous 1-Port Serial Mini-Physical Interface Module (Mini-PIM). The device to which you are
connecting and the serial interface types determine which type of cable you need.
Table 15: Juniper Networks Serial Cables
Connector TypeLengthInterface TypeProduct Number
Female3.04 m (10 ft)EIA530 cable (DCE)JX-CBL-EIA530-DCE
Male3.04 m (10 ft)EIA530 cable (DTE)JX-CBL-EIA530-DTE
30

Juniper SRX300 Series Specifications

General

Memory	4 GB
CPU	Intel Atom
Storage	8 GB
Operating Temperature	32°F to 104°F (0°C to 40°C)
Humidity	10% to 90% noncondensing
