Table 23: V.35 DTE Cable Pinouts for the 1-Port Serial Mini-PIM (continued)
DescriptionLFH-60 PairingM/34 PinLFH-60 Pin
Transmit Data (A)59P60
Receive Data (A)2R1
Transmit Data (B)60S59
Receive Data (B)1T2
Terminal Timing (A)51U52
Receive Timing (A)6V5
Terminal Timing (B)52W51
Receive Timing (B)5X6
Transmit Timing (A)55Y56
Transmit Timing (B)56AA55
---22 to 21
---26 to 25
---18 to 17
X.21 DCE and DTE Cable Pinouts
IN THIS SECTION
X.21 DCE Cable Pinouts for the 1-Port Serial Mini-Physical Interface Module | 43
X.21 DTE Cable Pinouts for the 1-Port Serial Mini-Physical Interface Module | 43
42

Juniper SRX300 Series Specifications

General

Memory	4 GB
CPU	Intel Atom
Storage	8 GB
Operating Temperature	32°F to 104°F (0°C to 40°C)
Humidity	10% to 90% noncondensing
