Juniper SRX300 Series Reference Guide

Antenna Specifications
The Mini-PIM supports two multi-band swivel-mount dipole antennas, which can be rotated 360 degrees.
You can rotate the antennas and select the angle at which the signal strength is high. Table 54 on page 94
lists the specifications for the antenna.
Table 54: Specifications for the Wi-Fi Mini-PIM Antenna
ValueSpecification
EDA-1713-25GR2-A3 (Vendor: MAG.LAYERS)Part number
•
2.4~2.5 GHz
•
5.15~5.85 GHz
Operating frequency range
50 ohmImpedance
2 (maximum)Voltage standing wave ratio (VSWR)
10 dB (maximum)Return loss
OmnidirectionalRadiation
5dBi +/-0.5Peak gain
LinearPolarization
–4° F (–20° C) to 149° F (65° C)Operating temperature
RP-SMAConnector type
Channels and Frequencies Supported on the Wi-Fi Mini-PIM
The Wi-Fi Mini-PIM supports channel bandwidths of 20 MHz, 40 MHz, and 80 MHz. The 2.4 GHz radio
supports 20 MHz and 40 MHz channel bandwidths, and the 5 GHz radio supports 20 MHz, 40 MHz, and
80 MHz channel bandwidths. You can configure the bandwidth by using the set wlan access-point ap-name
radio [1|2] radio-option channel bandwidth bandwidth command.
NOTE: You can configure the 80 MHz channel bandwidth only on the 5 GHz radio.
94

Juniper SRX300 Series Specifications

General

Memory	4 GB
CPU	Intel Atom
Storage	8 GB
Operating Temperature	32°F to 104°F (0°C to 40°C)
Humidity	10% to 90% noncondensing
