Juniper SRX300 Series Reference Guide

Table 22: V.35 DCE Cable Pinouts for the 1-Port Serial Mini-PIM (continued)
DescriptionLFH-60 PairingM/34 PinLFH-60 Pin
Terminal Timing (A)6U5
Receive Timing (A)51V52
Terminal Timing (B)5W6
Receive Timing (B)52X51
Transmit Timing (A)55Y56
Transmit Timing (B)56AA55
---22 to 21
--26 to 25
V.35 DTE Cable Pinouts for the 1-Port Serial Mini-Physical Interface Module
Table 23 on page 41 describes the V.35 DTE cable pinouts.
Table 23: V.35 DTE Cable Pinouts for the 1-Port Serial Mini-PIM
DescriptionLFH-60 PairingM/34 PinLFH-60 Pin
Frame Ground-A15
Signal Ground-B57
Request to Send-C48
Clear to Send-D37
Data Set Ready-E9
Received Line Signal Detector-F13
Data Terminal Ready-H33
Test Mode-K41
41

Juniper SRX300 Series Specifications

General

Memory	4 GB
CPU	Intel Atom
Storage	8 GB
Operating Temperature	32°F to 104°F (0°C to 40°C)
Humidity	10% to 90% noncondensing
