PR-23 instrucon manual
Prism wash
-SN = Integral steam nozzle, AISI 316 L -SN
-WN = Integral water nozzle, AISI 316 L -WN
-WP = Integral pressurized water nozzle, AISI 316 L
(A) This opon may aect delivery me
(B) Available with STR Indicang transmier and IS isolator only
9.4.2 PR-23-AP mounng hardware model code
Mounng hardware for PR-23-AP sensor
Part number and descripon Part no.
VFMA-23-PSS = Tank boom ange for PR-23-AP, MT4 DN 25/1T VFMA-23-PSS
VFBP-23-PSS = Tank boom blind ange for PR-23-AP, MT4 DN 25/1T VFBP-23-PSS
VFME-23-VSS = Mount adaptor for PR-23-AP-62-VSS HEXNUT type VFME-23-VSS
VFMF-23-VSS = Mount adaptor for PR-23-AP-62-VSS HEXNUT extended VFMF-23-VSS
Model and descripon Model
AP = Adapter for PR-23-AP AP
Sensor type
-T = Sanitary 3A-clamp, 2½ inch, inseron lenght 170 mm -T
-ZP = Sanitary I-line male (14 WI) 2½ inch, inseron length 178 mm -ZP
Material of construcon
SS = AISI 316 L SS
Process connecon
-P = MT4 DN 25/1T Tank boom ange, ush mounted -P
Inseron length adapter
30 = 30 mm 30
Prism wash
-SN = Integral steam nozzle, AISI 316 L -SN
-WP = Integral pressurized water nozzle, AISI 316 L -WP
-WN = Integral water nozzle, AISI 316 L -WN
Model and descripon Model
WNA = Wash nozzle adapter WNA
Sensor type
-T = Sanitary 3A-clamp, 2½ inch, inseron lenght 170 mm -T
-ZP = Sanitary I-line male (14 WI) 2½ inch, inseron length 178 mm -ZP
Material of construcon
SS = AISI 316 L SS
