6
PR-23 instrucon manual
2.2 Mounng the sensor
The sensor mounting location should be chosen with care to ensure reliable read-
ings from the process. Some basic rules, described in this section, apply to all sensor
models. The model speciic instructions can be found in Chapter 9, “Sensor speciica-
tions”. For the Sanitary compact refractometer PR-23-AC see Section 9.3, for the Probe
sanitary refractometer PR-23-AP see Section 9.4, for the Process probe refractometer
PR-23-GP see Section 9.6, for the Telon body refractometer PR-23-M and Telon body
semicon refractometer PR-23-MS see Section 9.8 and for the Saunders body refrac-
tometer PR-23-W see Section 9.9. For mounting an ATEX/FM/CSA approved sensor
in explosive atmosphere, see Section 9.10.2. For mounting an intrinsically safe refrac-
tometer PR-23-...-IA, see Section 9.11. For mounting of the Safe-Drive™ system with
the PR-23-SD sensor, see Section 11.4.
2.2.1 Choosing sensor mounng locaon
A K-Patents inline refractometer sensor can be located either indoors or outdoors in
most climates. However, when a sensor is located outdoors, some basic protection
against direct exposure to sunlight and rain should be provided. Special care should be
taken if the pipe wall is translucent (e.g. of iberglass), as light from outside reaching
the prism through the pipe wall may disturb the measurement.
The mounting location needs to be such that sediments or gas bubbles cannot accu-
mulate by the sensor. Good low velocity is essential in keeping the prism clean.
Important: If the process pipe vibrates, support the pipe. A vibrating pipe might
damage the in-line sensor mounted on it.
Always check that the sensor head is kept cool enough; the sensor head should not be
too hot to keep a hand on. The sensor cover should not be exposed to high temperature
radiation. In most cases, draft and natural convection provide suficient air cooling if
the air gets to low freely around the sensor head.
Additional cooling is necessary when the ambient temperature is higher than 45 °C
(113 °F) or when the process temperature is above 110 °C (230 °F) and the ambient
temperature is above 35 °C (95 °F). The air cooling is improved by blowing pressurized
air against the sensor cover. The pressurized air can be supplied by the ventilation
system. If no air is available it is also possible to install water cooling with PR-10038
cooling cover (except for PR-23-SD where sensor head needs to be kept in original
size for insertion and retraction).
Important: Always mount the sensor so that the interconnecting cable points down-
wards from the sensor head.
