K-Patents PR-23 - PR-23-GC Mounting Specifics

102
PR-23 instrucon manual
9.5.4 PR-23-GC mounng specics
The Compact refractometer is mounted either in a pipe elbow by a Sandvik coupling
connection or in a straight pipe via a Wafer low cell or a Pipe low cell. Both low
cell mounting designs create optimum low velocity on the measurement surface pro-
viding a good self-cleaning effect. The Wafer low cell has also an optional automatic
wash system capability.
In a pipe at least 2.5" in diameter the sensor is mounted in a pipe elbow with a Sand-
vik coupling. In a 2" pipe the sensor is mounted in a pipe elbow via reducing ferrule
PR-9283. In 0.5, 1 and 1.5 inch pipes a low cell is installed in a straight pipe. The
langeless Wafer low cell is a compact alternative to traditional low cells. The Wafer
refers to a low cell body that is installed between DIN, ANSI or JIS piping langes with
bolts and nuts. The Wafer low cell is a one-piece body construction with no welds. A
Pipe low cell is also available for 0.5 and 1 inch pipes.
$
$









6(&7,21$$




Figure 9.12 Mounng the sensor in a pipe 2 1/2" or larger
