10 Indicang transmier DTR specicaons
147
10 Indicang transmier DTR specicaons
Model: INDICATING TRANSMITTER
Product code: DTR-U-GP-AC
S/N: T06802
Tag:
100-240 V AC, 50/60 Hz, 30 VA
Made by K-PATENTS Oy, Vantaa, Finland
www.kpatents.com
IP66
Model: INDICATING TRANSMITTER
Product code: DTR-M-GP-DC-DD
S/N: T06816
Tag:
24 V DC, 30 VA
Made by K-PATENTS Oy, Vantaa, Finland
www.kpatents.com
IP66
AC label DC label
Figure 10.1 Indicang transmier DTR serial number label
Model: INDICATING TRANSMITTER
Product code: STR-M-GP-AC
S/N: T06820
Tag:
100-240 V AC, 50/60 Hz, 30 VA
Made by K-PATENTS Oy, Vantaa, Finland
www.kpatents.com
IP66
Model: INDICATING TRANSMITTER
Product code: STR-M-GP-DC
S/N: T06817
Tag:
24 V DC, 30 VA
Made by K-PATENTS Oy, Vantaa, Finland
www.kpatents.com
IP66
AC label DC label
Figure 10.2 Indicang transmier STR serial number label
10.1 Compability
The Indicating transmitter DTR is only compatible with the PR-23 refractometer
range. Any one or two PR-23 refractometer sensors can be connected to the DTR.
PR-01 and PR-03 refractometer sensors are not compatible with an Indicating trans-
mitter DTR.
For intrinsically safe installations (see Section 9.11) there is a single-sensor version
of the transmitter (STR). The information given in this chapter applies to STR as well,
unless otherwise indicated.
