172
PR-23 instrucon manual
11.6 Wash nozzle inseron and removal
11.6.1 Wash nozzle inseron
Check the nozzle and the valve before installing the wash nozzle. Use thread seal tape
for all thread connections.
Warning! Always shut the main steam valve before performing any work on the wash
nozzle.
1
1
3
2
!
1. Insert the nozzle into the isolaon valve
(1).
2. Aach the nozzle to the nozzle guide with
one special
M5x10 screw (2) using a 5 mm
allen key.
3. Remove the safety pin (3).
2
1
5
4
3
2
CLOSE
OPEN
1. Close the 1/4’’ check port valve under the
nozzle isolaon valve (1).
2. Open the isolaon valve (2) by turning the
handle counterclockwise.
3. Push the nozzle to the process (3).
4. Aach the nozzle to the nozzle guide with
one special
M5x10 screw (4) using a 5 mm
allen key.
5. Lock the isolaon valve handle with the
safety pin (5).
3
OPEN
1
2
3
1.1 STEAM: Connect the steam line and sensor
ush exible line to the nozzle T-piece (1,2).
1.2 WATER: Connect the water line to 1/4"
valve (1,2). 2. Open the steam supply line
valve (3).
3. Check the funconlity of washing from the
opcal image window in DTR.
