1. Li open Outer casing locking latch.
2. Rotate Outer casing 60° counterclockwise so that the
handle comes up on top.
12 Take a rm hold on the hand-wheel and the handle and
pull out Retractor with sensor inside.
Warning! A rm hold of the tool is essenal as the
combinaon of the tool and the sensor is noceably
heavier than Retractor alone.
Note: To ensure Isolaon valve aer the Safe-Drive tool
with the sensor has been removed, you can bolt a
standard ANSI 1.5” 105 lbs blind ange to Isolaon
valve with ½” (M12) bolts and nuts.
A lock can be added to Isolaon valve handle.
Warning! The sensor p is hot and may be covered
with liquor. It is recommended to rinse the sensor p
and Isolaon valve with hot water.
13 Put Retractor with sensor onto a table or similar surface
so that the hand-wheel has space to turn.
1. Turn the hand-wheel counterclockwise to drop the
thread, i.e. unl Outer casing is no longer connected to
the parts inside.
2. Pull o Outer casing.
14 1. Open the latch on Inner casing. 2. Keep sensor
steady with one hand and rotate Inner casing
counterclockwise with the other hand to unlock Inner
casing from sensor. 3. Pull o the sensor.
