K-Patents PR-23 User Manual

88
PR-23 instrucon manual
A
A
A
D
45°
B
C
D
SECTION A-A
SCALE 1 : 2
Flow cell type
A
B C D
AFC-HSS-H20-SI
48.6
48.6 51.6 89.0
AFC-HSS-H20-RI
35.6
48.6 51.6 89.0
AFC-HSS-H25-SI
60.3
60.3 64.1 108.0
Figure 9.7 Flowcell AFC-HSS-
H20 for pipe diameter 2" (50 mm) and H25 for pipe diameter 2 1/2" (65 mm)
A
A
A
B
C
D
D
45°
B
B
SECTION A-A
SCALE 1 : 2
1
3
2
1
2
3
5
4
45°
SECTION B-B
SCALE 1 : 5
10
6
11
Flow cell type A
B C D
AFC-HSS-H20-SI-NC 48.6
48.6 51.6 89.0
AFC-HSS-H20-RI-NC
35.6
48.6 51.6 89.0
AFC-HSS-H25-SI-NC
60.3
60.3 64.1 108.0
Figure 9.8 Flowcell AFC-HSS- with wash nozzle connecon (-NC)
H20 for pipe diameter 2" (50 mm) and H25 for pipe diameter 2 1/2" (65 mm)
