KEB F6 User Manual

Parameter Descriptions
150
© 2024 KEB America, Inc.
LL06 Encoder Pole Position Learn
Learns the motor pole position (encoder position) and encoder A/B channel phasing with
movement, for synchronous motors. Method requires relatively frictionless load (un-roped
sheave or balanced car).  Refer to LE06 Encoder 1 Pole Position.
Pole Position Learn section, pg. 71 for procedure.
Motor
Type
Setting Options
NUM
Range
Units
Default
Pass
Level
Ind.
PM
Min.
Max.
Imp.
Met.
RW
RW
Tune Activation
-
0
255
-
-
0
Basic
OFF
0
-
-
-
-
-
-
Start
1
Tune Active
2
Tune Complete
4
Tune Failed
8
Tune State
-
off
0
USER: Run empty car UP on
Inspection Speed
16
STATUS: Determining encoder
pole offset
32
USER: End the run
48
FAILURE: Speeds not correct,
verify encoder
PPR/Signal/Mounting
64
STATUS: Motor current too large,
swapping encoder phases, run the
car UP again
80
USER: Did the elevator travel UP?
96
STATUS: Reversing motor
direction, run the car UP again
112
FAILURE: Encoder error detected,
verify encoder
PPR/Signal/Mounting
128
FAILURE: Minimum measurement
speed not reached, increase
speed, run the car UP again
144
SUCCESS: Encoder Pole Learn
complete
160
Cannot start tune because another
tune mode is already active
176
ERROR: Tune Motor with LL01 first
192
