KEB F6 User Manual

Parameter Descriptions
© 2024 KEB America, Inc.
155
LL18 NTSD Tune Mode
The NTSD Tune Mode can be used to automatically determine and set the NTSD
slowdown points.
When activated, run the elevator to either terminal floor. The motor speed when the
NTSD switches are passed and the NTSD inputs are dropped will be learned during the
run and displayed after the end of the run. There will also be the option to automatically
set the TS03 - 08 Speed Thresholds for the corresponding NTSD input thresholds and
direction of travel from the learn run. If values are automatically set from the learn run,
the value entered will be 10% above the speed at which the input was dropped. After the
learn run has been completed, the drive will return to normal operation.
Motor
Type
Setting Options
NUM
Range
Units
Default
Pass
Level
Ind.
PM
Min.
Max.
Imp.
Met.
RW
RW
Tune Activation
-
0
255
-
-
0
Basic
0
-
-
-
-
-
-
OFF
1
Start
2
Tune Active
3
Tune State
-
off
0
USER: Run elevator at High
Speed, from terminal landing to
terminal landing
16
STATUS: Running elevator
32
USER: Accept the learned
thresholds?
48
FAILURE: No NTSD input was
activated
64
SUCCESS: NTSD Tune complete
160
Cannot start tune because another
tune mode is already active
176
User Input
-
0
Yes
4
No
8
Waiting for input
12

KEB F6 Specifications

General

Category	Inverter
Protection Class	IP20
Communication Interfaces	PROFIBUS, CANopen, RS485
Operating Temperature	-10°C to +50°C
Series	F6
Output Frequency	0 Hz to 600 Hz
Protection Features	Overcurrent, Overvoltage, Undervoltage, Short circuit
Humidity	5% to 95% (non-condensing)
Altitude	Up to 1000 m above sea level
Control Modes	Sensorless vector control
Storage Temperature	-25°C to +70°C
