KEB F6 User Manual

Parameter Descriptions
© 2024 KEB America, Inc.
85
US05 Load Configuration
After entering the basic setup parameters (US02-US04 & US06) the system configuration
must be written to the drive. This procedure loads the drive with the correct parameters
depending on the motor type and sets the correct limits and scaling.
Upon successful loading, US05 will display Configuration OK. When the elevator drive
needs to be reconfigured, US05 will display Not Configured US05 will need to be set to

A user can also save/load OEM defaults and read/write to various memory locations.
If the parameters US02 System Units, US03 Motor Type, or US04 Control Type are
changed, the configuration will need to be reloaded in US05 for changes to take effect.
When OEM defaults or saved user parameters have not been created, and they are
attempted to be loaded, US05 will show missing parameter backup.
Motor Type
Setting Options
NUM
Range
Units
Default
Pass
Level
Ind.
PM
Min.
Max.
Imp.
Met.
RW
RW
Load Configuration
-
0
99
-
-
0
Basic
Not configured
0
-
-
-
-
-
-
Configuration OK
1
Write Configuration
2
Save Lift Parameters Only
3
Write config. to flash
4
Read config. from flash
5
Reserved
6
Reserved
7
Create OEM defaults
8
Restore OEM defaults
9
Restore KEB defaults
10
Config File Missing/Error
99
Backup File
-
No File Load Error
0
Missing Parameter Backup
128
If the US03 Motor Type is changed, then a subsequent Write Configuration to
Drive will result in the defaulting of drive parameters.
US06 Contract Speed
This parameter sets the contract speed which serves as an upper speed limit for normal
operation.
An overspeed level is automatically set at 110% of this value.
Motor Type
Range
Units
Default
Pass
Level
Ind.
Ind.
Min.
Max.
Imp.
Met.
RW
RW
0
8.1
m/s
0
Basic
0
1600
ft/min
0
Basic
