Keithley 2002 User Manual

Keithley Instruments, Inc.
28775 Aurora Road
Cleveland, Ohio 44139
1-888-KEITHLEY
www.keithley.com
Specifications are subject to change without notice.
SPEC-2002 Rev. H / February 2009 Page 3 of 14
Model 2002
Multimeter Specifications
DCV READING RATES
12,17
Readings/Second to Memory
Readings/Second to IEEE-488
18
Readings/Second with Time
Stamp to IEEE-488
18
PLC
Measurement
Aperture Bits
Default
Digits
Autozero Off Autozero On Autozero Off Autozero On Autozero Off Autozero On
10 167 ms (200 ms) 29 8½ 6 (5) 2 (1.7) 6 (5) 2 (1.6) 6 (5) 2 (1.6)
2 33.4 ms (40 ms) 27 7½ 29 (25) 9 (7.6) 29 (24) 9 (7.4) 27 (22) 9 (7.4)
1 16.7 ms (20 ms) 26 7½ 56 (48) 47 (40) 55 (45) 46 (38) 50 (41) 42 (34)
0.2 3.34 ms (4 ms) 23 6½ 235 (209) 154 (137) 225 (200) 146 (130) 152 (135) 118 (105)
0.1 1.67 ms (2 ms) 22 6½ 318 (305) 173 (166) 308 (295) 168 (161) 181 (174) 121 (116)
0.02 334 µs (400 µs) 20 5½ 325 (325) 179 (179) 308 (308) 173 (173) 182 (182) 124 (124)
0.01 167 µs (167 µs) 19 4½ 390 (390) 186 (186) 365 (365) 182 (182) 201 (201) 125 (125)
0.01
11
167 µs (167 µs) 19 4½ 2000 (2000) 2000 (2000)
Linearity: <0.1ppm of range typical, <0.2ppm maximum.
Zero Stability: Typical maximum variation in 1 hour, T
REF ± 0.5°C, 7H-digit resolution, 10-reading digital filter, synchronous autozero.
Range 1 PLC 10 PLC
200 mV
4
± 60 counts ± 40 counts
2 V
4
± 6 counts ± 4 counts
20 V ± 4 counts ± 1 count
200 V ± 5 counts ± 2 counts
1000 V ± 2 counts ± 1 count
Polarity Reversal Error: This is the portion of the instrument error that is seen when HI and LO are reversed. This is not an additional error—it
is included in the overall instrument accuracy specification.
Reversal Error: <4 counts at 10V input at 7H digits, 10 power line cycles, synchronous autozero, 10-reading repeat digital filter.
Input Bias Current: <100pA at 25°C.
Settling Characteristics: <50µs to 10ppm of step size for the 200mV–20V ranges. <1ms to 10ppm of step size for the 200V and 1000V
ranges. Reading settling times are affected by source impedance and cable dielectric absorption characteristics.
Autoranging: Autoranges up at 105% of range, down at 10% of range.
DCV PEAK SPIKES MEASUREMENT
REPETITIVE SPIKES ACCURACY
19
90 Days, 1 Year or 2 Years, T
CAL
±5°C ±(% of reading+% of range)
Range 0–1kHz
20
1kHz–
10kHz
10kHz–
30kHz
30kHz–
50kHz
50kHz–
100kHz
100kHz–
300kHz
300kHz–
500kHz
500kHz–
750kHz
750kHz–
1MHz
Temperature Coefficient
±(% of reading +% of range)/°C
Outside TCAL ±5°C
200 mV 0.08+0.7 0.09+0.7 0.1 +0.7 0.15+0.7 0.25+0.7 1.0+0.7 2.5+0.7 5.5+0.7 9+0.7 0.002+0.03
2 V 0.08+0.3 0.09+0.3 0.1 +0.3 0.15+0.3 0.25+0.3 1.0+0.3 2.5+0.3 5.5+0.3 9+0.3 0.002+0.03
20 V 0.1 +0.7 0.11+0.7 0.14+0.7 0.19+0.7 0.25+0.7 1.0+0.7 2.5+0.7 5.5+0.7 9+0.7 0.004+0.03
200 V
21
0.1 +0.3 0.11+0.3 0.14+0.3 0.19+0.3 0.25+0.3
1.0+0.3
22
2.5+0.3
22
5.5+0.3
22
9+0.3
22
0.004+0.03
1000 V
21
0.12+0.6 0.16+0.6 0.2 +0.6 0.25+0.6
22
0.5 +0.6
22
0.01 +0.02
Max. % of Range ±125% ±125% ±125% ±125% ±125% ±125% ±125% ±100% ±75%
Default Measurement
Resolution: 3H digits.
Maximum Input: ±1100V peak value, 2x10
7
V·Hz (for inputs above 20V).
Non-Repetitive Spikes: 10% of range per µs typical slew rate.
Spike Width: Specifications apply for spikes 1µs.
Range Control: In Multiple Display mode, voltage range is the same as DCV range.
Spikes Measurement Window: Default is 100ms per reading (settable from 0.1 to 9.9s in Primary Display mode).
Input Characteristics: Same as ACV input characteristics.
Spikes Display: Access as multiple display on DC Volts. First option presents positive peak spikes and highest spike since reset. Second
option presents negative spikes and lowest spike. Highest and lowest spike can be reset by pressing DCV function button. Third option
displays the maximum and minimum levels of the input signal. Spikes displays are also available through CONFIG-ACV-ACTYPE as primary
displays.
17
For on-scale readings, no trigger delays, internal trigger, digital filter off, normal autozero, display off, SREAL format. These rates are for 60Hz and (50Hz). Rates
for 400Hz equal those for 50Hz.
18
Using Internal Buffer.
19
Specifications apply for sine wave input with a 10-reading digital filter. If no filter is used, add 0.25% of range typical uncertainty.
20
Specifications assume AC+DC coupling for frequencies below 200Hz. Below 20Hz add 0.1% of reading additional uncertainty.
21
Add 0.001% of reading × (VIN/100V)
2
additional uncertainty for inputs above 100V.
22
Typical values.

Keithley 2002 Specifications

General

Resolution	8.5 digits
DC Voltage Accuracy	±0.0006%
Maximum DC Voltage	1000 V
Maximum AC Voltage	750 V
Maximum DC Current	3 A
Maximum AC Current	3 A
Connectivity	GPIB, RS-232
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
Resistance Range	10 Ω to 1 GΩ
Model	2002
Category	Multimeter
Interface	GPIB, RS-232
AC Current Accuracy	±0.1%
Frequency Range	0.1Hz to 300kHz
Display	VFD
Type	Digital
Power Supply	100-240V AC, 50/60Hz
Current Range (DC)	100 μA to 3 A
Current Accuracy (DC)	±0.01%
Current Range (AC)	100 μA to 3 A
Current Accuracy (AC)	±0.1%
DC Current Range	100 μA to 3 A
AC Current Range	100 μA to 3 A
