Model 2002
Multimeter Specifications
AC VOLTS
ACV INPUT CHARACTERISTICS
Rms Range Peak Input Full Scale rms Resolution Input Impedance
Temperature Coefficient
23
±(% of reading + % of range) / °C
Outside T
CAL
±5°C
200 mV 1 V 210.0000 100 nV 1M ±2% with <140pF 0.004 + 0.001
2 V 8 V 2.100000 1 µV 1M ±2% with <140pF 0.004 + 0.001
20 V 100 V 21.00000 10 µV 1M ±2% with <140pF 0.006 + 0.001
200 V 800 V 210.0000 100 µV 1M ±2% with <140pF 0.006 + 0.001
750 V 1100 V 775.000 1 mV 1M ±2% with <140pF 0.012 + 0.001
AC Voltage Uncertainty = ±[ (% of reading) x (measured value) + (% of range ) x (range used) ] / 100.
PPM Accuracy = (% accuracy) x 10,000.
0.015% of Range = 30 counts for ranges up to 200V and 113 counts on 750V range at 5H digits.
LOW FREQUENCY MODE RMS
24
90 Days, 1 Year or 2 Years, ±2°C from last AC self-cal, for 1% to 100% of range
25
, ±(% of reading + %
of range)
Range 1–10Hz
22
10–50Hz 50–499Hz 501Hz–2kHz 2–10kHz 10–30kHz 30–50kHz 50–100kHz 100–200kHz 0.2–1MHz 1–2MHz
200 mV 0.09+0.015 0.06+0.015 0.035+0.015 0.03+0.02 0.02+0.02 0.025+0.02 0.05+0.02 0.3+0.015 0.75+0.025 2+0.1 5+0.2
2 V 0.09+0.015 0.04+0.015 0.025+0.015 0.02+0.02 0.02+0.02 0.025+0.02 0.05+0.02 0.3+0.015 0.75+0.025 2+0.1 5+0.2
20 V 0.1 +0.015 0.06+0.015 0.035+0.015 0.03+0.015 0.04+0.015 0.05 +0.015 0.07+0.015 0.3+0.015 0.75+0.025 4+0.2 7+0.2
22
200 V
21
0.1 +0.015 0.05+0.015 0.03 +0.015 0.03+0.015 0.04+0.015 0.05 +0.015 0.07+0.015 0.3+0.015 0.75+0.025
22
4+0.2
22
750 V
21
0.13+0.015 0.09+0.015 0.05 +0.015 0.05+0.015 0.06+0.015 0.08 +0.015 0.1 +0.015
22
0.5+0.015
22
NORMAL MODE RMS
24
90 Days, 1 Year or 2 Years, ±2°C from last AC self-cal, for 1% to 100% of range
25
, ±(% of reading + % of range)
Range 20–50Hz 50–100Hz 0.1–2kHz 2–10kHz 10–30kHz 30–50kHz 50–100kHz 100–200kHz 0.2–1MHz 1–2MHz
200 mV 0.25+0.015 0.07+0.015 0.02+0.02 0.02+0.02 0.025+0.02 0.05+0.02 0.3+0.015 0.75+0.025 2+0.1 5+0.2
2 V 0.25+0.015 0.07+0.015 0.02+0.02 0.02+0.02 0.025+0.02 0.05+0.02 0.3+0.015 0.75+0.025 2+0.1 5+0.2
20 V 0.25+0.015 0.07+0.015 0.03+0.015 0.04+0.015 0.05 +0.015 0.07+0.015 0.3+0.015 0.75+0.025 4+0.2 7+0.2
22
200 V
21
0.25+0.015 0.07+0.015 0.03+0.015 0.04+0.015 0.05 +0.015 0.07+0.015 0.3+0.015 0.75+0.025
22
4+0.2
22
750 V
21
0.25+0.015 0.1 +0.015 0.05+0.015 0.06+0.015 0.08 +0.015 0.1 +0.015
22
0.5+0.015
22
dB ACCURACY RMS ±dB, 90 Days, 1 Year or 2 Years, TCAL ±5°C, Reference=1V, Autoranging, Low Frequency Mode, AC+DC Coupling
Input 1–100Hz 0.1–30kHz 30–100kHz 100–200kHz 0.2–1MHz 1–2MHz
–54 to –40 dB (2 mV to 10 mV) 0.230 0.225 0.236 0.355
–40 to –34 dB (10 mV to 20 mV) 0.036 0.031 0.041 0.088
–34 to 6 dB (20 mV to 2 V) 0.023 0.018 0.028 0.066 0.265 0.630
6 to 26 dB (2 V to 20 V) 0.024 0.024 0.028 0.066 0.538 0.820
22
26 to 46 dB (20 V to 200 V) 0.024 0.024 0.028 0.066
22
0.538
22
46 to 57.8 dB (200 V to 775 V) 0.018 0.021 0.049
22
ACV READING RATES
17, 22
Readings/Second to Memory Readings/Second to IEEE-488
18
Readings/Second with
Time Stamp to IEEE-488
18
PLC
Measurement
Aperture Bits
Default
Digits
Autozero Off Autozero On Autozero Off Autozero On Autozero Off Autozero On
10 167 ms (200 ms) 29 6H 6 (5) 2 (1.7) 6 (5) 2 (1.6) 6 (5) 2 (1.6)
2 33.4 ms (40 ms) 27 5H 29 (25) 9 (7.6) 28 (23) 9 (7.4) 26 (21) 9 (7.4)
1 16.7 ms (20 ms) 26 5H 56 (48) 47 (40) 52 (43) 44 (36) 48 (39) 40 (33)
0.2 3.34 ms (4 ms) 23 5H 145 (129) 110 (98) 131 (117) 100 (88) 102 (91) 79 (70)
0.1 1.67 ms (2 ms) 22 5H 150 (144) 112 (108) 132 (127) 101 (97) 102 (98) 80 (77)
0.02 334 µs (400 µs) 20 5H 150 (150) 115 (115) 132 (132) 103 (103) 102 (102) 80 (80)
0.01 167 µs (167 µs) 19 4H 382 (382) 116 (116) 251 (251) 103 (103) 163 (163) 80 (80)
0.01
13
167 µs (167 µs) 19 4H 2000 (2000) 2000 (2000)
23
Temperature coefficient applies to rms and average readings. For frequencies above 100kHz, add 0.01% of reading/°C to temperature coefficient.
24
Specifications apply for sinewave input, AC + DC coupling, 1 power line cycle, autozero on, digital filter off, following 55-minute warm-up.
25
For 1% to 5% of range below 750V range, and for 1% to 7% of 750V range, add 0.01% of range uncertainty. For inputs from 200kHz to 2MHz, specifications
apply above 10% of range.

Keithley 2002 Specifications

General

Resolution	8.5 digits
DC Voltage Accuracy	±0.0006%
Maximum DC Voltage	1000 V
Maximum AC Voltage	750 V
Maximum DC Current	3 A
Maximum AC Current	3 A
Connectivity	GPIB, RS-232
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
Resistance Range	10 Ω to 1 GΩ
Model	2002
Category	Multimeter
Interface	GPIB, RS-232
AC Current Accuracy	±0.1%
Frequency Range	0.1Hz to 300kHz
Display	VFD
Type	Digital
Power Supply	100-240V AC, 50/60Hz
Current Range (DC)	100 μA to 3 A
Current Accuracy (DC)	±0.01%
Current Range (AC)	100 μA to 3 A
Current Accuracy (AC)	±0.1%
DC Current Range	100 μA to 3 A
AC Current Range	100 μA to 3 A
