Keyscan CA150 User Manual

Keyscan Inc. A Member of the Kaba Group – CA150 Rev. B Installation Guide (07.15)
24
Figure 9 – Terminate Magnetic Lock over 500 mA - Fail Safe
12 VDC+
Mag Lock
- Fail Safe -
to N.C.
Ensure all lock hardware complies with federal, state/provincial, and municipal fire codes.
Ground
Lug
POWER
INOUT
-
+
-
+
DOOR
AUX.
N/C
(+)
COM
(-)
N/O
(+)
N/C
(+)
COM
(-)
N/O
(+)
RS-485
A
B
(+ 12 VDC)
CA150B
Control Board
Cut View
Fire Contact*
N.C.
breaks on alarm
Maglock Powered from Independent Power Supply
– over 500 mA
+12V DC
Power Supply
(for CA150)
+
+
-
-
J9
J8
J9
J8
Set J8 & J9 to Unpowered
# 18 AWG
# 18 AWG Green
Black
Red
Black Red
# 18 AWG
Maglock
Power
Supply
+
-
KI-00328E-11-12
12V DC power supply
or PoE for power to
control board
*RB5 Keyscan isolation relay
may be required if fire contact
is not a dry contact.
or
PoE
Keyscan recommends power supplies have back-up batteries.
