Keyscan CA150 User Manual

Keyscan Inc. A Member of the Kaba Group – CA150 Rev. B Installation Guide (07.15)
25
Figure 10 - Terminate Door Strike - 500 mA or less - Fail Safe
12 VDC+
Com
Ensure all lock hardware complies
with federal, state/provincial, and
municipal fire codes.
Ground
Lug
POWER
INOUT
-
+
-
+
DOOR
AUX.
N/C
(+)
COM
(-)
N/O
(+)
N/C
(+)
COM
(-)
N/O
(+)
RS-485
A
B
(+ 12 VDC)
CA150B
Control Board
Cut View
Fire Contact*
N.C.
breaks on alarm
Door Strike Powered from CA150
– must be less than 500 mA
12V DC
Power Supply
+
+
-
-
J9
J8
J9
J8
Set J8 & J9 to Powered
# 18 AWG
# 18 AWG Green
Red
Black
Black Red
# 18 AWG
+
-
Door
Strike
If using PoE with fail safe locking device, note that in the event of a
power outage the lock releases and the door is unsecure. Keyscan
recommends that the PoE switch is connected via a UPS or use a +12V
DC power supply with back-up battery.
KI-00329E-11-12
12V DC power supply
or PoE to CA150 for
power to all devices
*RB5 Keyscan isolation relay
may be required if fire contact
is not a dry contact.
DOOR
AUX.
N/C
(+)
COM
(-)
N/O
(+)
N/C
(+)
COM
(-)
N/O
(+)
CA150
Install diode at CA150
door terminal. Observe
correct polarity.
