Important
You may require the assistance of a qualified network administrator. Without correct host/remote network
settings and connectivity, you will be unable to establish communication.
Table 15 - Reverse Network IP Address Settings
Network Configuration – Internet/Intranet/WAN – Host Router or End Point with External IP
Address
Example
Settings
Host Location
Remote Location
See Figure 63
IP Address
Port #
Gateway
Encryption key
Router with port forward
or router table to
PC/server with Keyscan
reverse network encrypted
communication
Same encryption key/bit
setting as remote location
ACU
Programmed with host router or
end point external IP address
Port # of host router/end point
ACU Ethernet
Module
Programmed with static IP address
or if using DHCP server dynamic IP
Gateway (if static IP above)
Port # of host router/end point
Same encryption key/bit setting as
host location
Network Configuration – LAN – Closed Network with No Public Exposure
See Figure 64
IP Address
Port #
Encryption key
PC/server with Keyscan
reverse network encrypted
communication
Same encryption key/bit
setting as remote location
ACU
Programmed with IP address of
host PC/server with Keyscan
reverse network encrypted
communication
Port # of Host PC/server
ACU Ethernet
Module
Programmed with static IP address
or if using DHCP server dynamic IP
Port # of Host PC/server
Same encryption key/bit setting as
host location
