Keysight M8070A Programming Guide 403
SCPI Command Reference 5
:PLUGin:EDIagram:EVALuation Subnode
This subnode has the following SCPI structure:
This subnode has the following commands:
Table 79
:PLUGin:EDIagram:EVALuation:BERThresh[?]
Syntax :PLUGin:EDIagram:EVALuation:BERThresh 'Identifier', <ZERR | BTHR>
:PLUGin:EDIagram:EVALuation:BERThresh? 'Identifier'
Input
Parameters
Identifier: 'MyMeasurement'
Return Range ZERR | BTHR
Description This command tells how to calculate measurement results, such as, eye
height, eye width and JPPeak either using '0 errors' (ZERO) or a specific
'BER Threshold' (THReshold). In the latter case, numeric value of the
Name Description under
:BERThresh[?] :PLUGin:EDIagram:EVALuation:BERThresh[
?] on page 403
:BERThresh:THReshold[?] :PLUGin:EDIagram:EVALuation:BERThresh:
THReshold[?] on page 404
:TTIMe[?] :PLUGin:EDIagram:EVALuation:TTIMe[?] on
page 404
:EVALuation
:BERThresh[?]
:BERThresh:THReshold[?]
:TTIME[?]
