M8190A User Interface 2
M8190A User’s Guide 83
 (Delete data)
Click this icon to delete selected frequency rows.
Amplitude Table
 # (Amplitude ID)
Whenever a new amplitude row is created, it is automatically allocated a numeric
ID termed as #. First amplitude row has the # value as 1, second as 2, and so on.
 Amplitude
Enter the required amplitude value in the amplitude row.
 (Add data)
Click this plus (+) icon to add a new amplitude row.
 (Delete data)
Click this icon to delete selected amplitude rows.
Sequence Src. (Sequence Source)
 Channel 1
To extract and display the channel 1 sequencing configuration from the instrument,
select channel 1 as the sequence source.
 Channel 2
To extract and display the channel 2 sequencing configuration from the instrument,
select channel 2 as the sequence source.
 Read From Instr. (Instrument)
Use this button to read/extract the present sequencing configuration of the
instrument.
Sequence Des. (Sequence Destination)
 Channel 1
To send sequence configuration to channel 1 of the instrument, select channel 1 as
the sequence destination.
 Channel 2
To send sequence configuration to channel 2 of the instrument, select channel 2 as
the sequence destination.
 Send To Instr. (Instrument)
Use this button to send the sequence configuration to the instrument.
