4 System
4.6 Alignments
Example
:CAL:TIME:INT:RRH:LOS?
Notes Value in hours since the last successful Align LO Clock
Dependencies Only appears in VXT based solutions with M1741A/42A/49A/49B RRH
State Saved No
Backwards
Compatibility SCPI
:CALibration:TIME:INTernal:LOSync?
Query Temperature of Last Align LO Clock
Remote Command
:CALibration:TEMPerature:INTernal:RRHead:LOSync?
Example
:CAL:TEMP:INT:RRH:LOS?
Notes Value in degrees Centigrade when the last successful Align LO Clock was executed
Dependencies Only appears in VXT based solutions with M1741A/42A/49A/49B RRH
State Saved No
Backwards
Compatibility SCPI
:CALibration:TEMPerature:INTernal:LOSync?
Query Time since Last Align RRH Amplitude
Remote Command
:CALibration:TIME:INTernal:RRHead:AMPLitude?
Example
:CAL:TIME:INT:RRH:AMPL?
Notes Value in hours since the last successful Align RRH Amplitude
Dependencies Only appears in VXT based solutions with M1741A/42A/49A/49B RRH
State Saved No
Backwards
Compatibility SCPI
:CALibration:TIME:INTernal:RRHAmp?
Query Temperature of Last Align RRH Amplitude
Remote Command
:CALibration:TEMPerature:INTernal:RRHead:AMPLitude?
Example
:CAL:TEMP:INT:RRH:AMPL?
Notes Value in degrees Centigrade when the last successful Align RRH Amplitude was executed
Dependencies Only appears in VXT based solutions with M1741A/42A/49A/49B RRH
State Saved No
Backwards
Compatibility SCPI
:CALibration:TEMPerature:INTernal:RRHAmp?
Vector Modulation Analyzer Mode User's &Programmer's Reference 1928
