4 System
4.6 Alignments
Query Time since Last Align Now LO Leakage
Remote Command
:CALibration:TIME:INTernal:LOLeakage?
Example
:CAL:TIME:INT:LOL?
Notes Value in hours since the last successful Align Now LO Leakage
Dependencies Only appears in VXT models M9410A/11A/15A/16A
State Saved No
Query Temperature of Last Align Now LO Leakage
Remote Command
:CALibration:TEMPerature:INTernal:LOLeakage?
Example
:CAL:TEMP:INT:LOL?
Notes Value in degrees Centigrade when the last successful Align Now LO Leakage was executed
Dependencies Only appears in VXT models M9410A/11A/15A/16A
State Saved No
Query Time since Last Align Now IF Cable
Remote Command
:CALibration:TIME:INTernal:RRHead:IFCable?
Example
:CAL:TIME:INT:RRH:IFC?
Notes Value in hours since the last successful Align Now IF Cable
Dependencies Only appears in VXT based solutions with M1740A/41A/42A/49A/49B RRH
State Saved No
Backwards
Compatibility SCPI
:CALibration:TIME:INTernal:IFCable?
Query Temperature of Last Align Now IF Cable
Remote Command
:CALibration:TEMPerature:INTernal:RRHead:IFCable?
Example
:CAL:TEMP:INT:RRH:IFC?
Notes Value in degrees Centigrade when the last successful Align Now IF Cable was executed
Dependencies Only appears in VXT based solutions with M1740A/41A/42A/49A/49B RRH
State Saved No
Backwards
Compatibility SCPI
:CALibration:TEMPerature:INTernal:IFCable?
Query Time since Last Align LO Clock
Remote Command
:CALibration:TIME:INTernal:RRHead:LOSync?
1927 Vector Modulation Analyzer Mode User's &Programmer's Reference
