Jam Display bizhub C350 Field Service Ver.1.0 Mar. 2004
4-4
IV Troubleshooting
1.4.3 Paper Exit / Turnover section misfeed
A. Detection timing
B. Action
Type Description
Misfeed due to
paper remaining at
the Turnover Sen-
sor
Misfeed is detected if the Turnover Sensor (PC5-DF) is not turned OFF within a
preset time after the Turnover Sensor (PC5-DF) was tuned ON.
Misfeed due to
paper not reached
the Exit Sensor (in
the 2-Sided Mode)
Misfeed is detected if the Exit Sensor (PC6-DF) is not turned ON within a preset
time after the Turnover Sensor (PC5-DF) was turned ON in the 2-Sided mode.
Misfeed due to
paper remaining at
the Exit Sensor
Misfeed is detected if the Exit Sensor (PC6-DF) is not turned OFF within a preset
time after the Exit Sensor (PC6-DF) was tuned ON.
Relevant electrical parts
Turnover Sensor (PC5-DF)
Exit Sensor (PC6-DF)
Exit Motor (M3-DF)
Control Board (PWB-A DF)
Step Action
WIRING DIAGRAM
Control signal
Location
(Electrical compo-
nents)
1 Initial check items - -
2 PC5-DF I/O, sensor check PWB-A DF CN9A DF-3 G-2
3 PC6-DF I/O, sensor check PWB-A DF CN9A DF-6 H-2
4 M3-DF operation check - B-7
5 PWB-A DF replacement - E-5
