bizhub C350 Field Service Ver.1.0 Mar. 2004 Board switch
3-13
III Adjusting/Setting
4.2 PWB-B PK (Punch Control Board)
Symbol Description
1 SW1001 Used to register the number of punched holes and adjust the sensor output.
2 SW1002 Used to register the number of punched holes and adjust the sensor output.
3 SW1003 Used to register the number of punched holes and adjust the sensor output.
SW1001
LED1001
LED1002
LED1003
2
1
1
49
1
J1003
J1004
J1002 J1001 J1006
J1005
J1007
14
SW1002
SW1003
5
11
5
13
1
4583fs3514c0
[1]
[3]
[2]
