Jam Display bizhub C350 Field Service Ver.1.0 Mar. 2004
4-2
IV Troubleshooting
1.3 Sensor layout
[1] Duplex Unit Transport Sensor 1 PI1-DU [3] Duplex Unit Transport Sensor 2 PC1-DU
[2] Synchronizing Roller Sensor PC28
4535fs4502c0
[1]
[2]
[3]
C350_FS_E.book 2 ページ ２００４年３月１１日　木曜日　午後５時６分
