Trouble code bizhub C350 Field Service Ver.1.0 Mar. 2004
4-10
IV Troubleshooting
2.3.2 C0B05:Paddle Motor malfunctions
A. Detection timing
B. Action
Malfunction code Description
C0B05
The Paddle Home Position Sensor (PI2-FN) is not unblocked even after the lapse
of a given period of time after the Paddle has started moving from its home posi-
tion.
The Paddle Home Position Sensor (PI2-FN) is not blocked even after the lapse of a
given period of time after the Paddle has started moving from a position not the
home position.
The Swing Guide Home Position Sensor (PI3-FN) is not unblocked even after the
lapse of a given period of time after the Booklet Roller has started moving from its
home position.
The Swing Guide Home Position Sensor (PI3-FN) is not blocked even after the
lapse of a given period of time after the Booklet Roller has started moving from a
position not the home position.
Relevant electrical parts
Paddle Home Position Sensor (PI2-FN)
Swing Guide Home Position Sensor (PI3-FN)
Paddle Motor (M2-FN)
Finisher Control Board (PWB-A FN)
Step Action
WIRING DIAGRAM
Control signal
Location
(Electrical compo-
nents)
1
Check the motor and sensor connectors
for proper connection, and correct as
necessary.
--
2
Check the connector of motor for proper
drive coupling, and correct as neces-
sary.
--
3 PI2-FN I/O, sensor check PWB-A FN CN9 FN-2 H-5
4 PI3-FN I/O, sensor check PWB-A FN CN9 FN-8 I-5
5
M2-FN operation check when the Power
Switch is turned OFF and ON.
-A-9
6 PWB-A FN replacement - E-6
