Konica Minolta bizhub C350 Service Manual

Jam Display bizhub C350 Field Service Ver.1.0 Mar. 2004
4-4
IV Troubleshooting
1.4.2 Tray1 Exit section misfeed
A. Detection timing
B. Action
1.4.3 Job Tray Exit section misfeed (JS-601)
A. Detection timing
B. Action
Type Description
Tray1 Exit section
misfeed detection
The 1st Tray Exit Sensor (PC1-FN) is not unblocked even after the lapse of a
given period of time after it has been blocked.
Relevant electrical parts
1st Tray Exit Sensor (PC1-FN) Control Board (PWB-A FN)
Step Action
WIRING DIAGRAM
Control signal
Location
(Electrical compo-
nents)
1 Initial check items - -
2 PC1-FN I/O, sensor check PWB-A FN PJ19A FN-6 G-9
3 PWB-A FN replacement - E-5
Type Description
Job Tray Exit sec-
tion misfeed detec-
tion (JS-601)
The Job Tray Exit Sensor (PC19-FN) is not unblocked even after the lapse of a
given period of time after it has been blocked.
Relevant electrical parts
Job Tray Exit Sensor (PC19-FN) Control Board (PWB-A FN)
Step Action
WIRING DIAGRAM
Control signal
Location
(Electrical compo-
nents)
1 Initial check items - -
2 PC19-FN I/O, sensor check PWB-A FN PJ14A FN-6 B-9
3 PWB-A FN replacement - E-5
