(2) Wire harness (3) Clamp
• Do not pinch the wire harness when installing parts.
(4) Wire harness (L) Bad
9. Handling fuses
• Always use fuses of the specified capacity.
• Do not use steel or copper wiring instead of fuse.
• Do
not install work light or radio without auxiliary
power line.
• Do not install auxiliaries to the fuses. The fuses
may blow.
(1) Fuse
(2) Fusible link
(3) Slow blow fuse
10. Handling connectors
•
When disconnecting the
locking connectors, be
sure to disengage the lock before disconnecting.
There are two kinds of locks: one requires pressing
and the other requires pulling.
(A) Press
• Hold
on tightly to the connectors when
disconnecting them.
•
Do not pull wire harness itself.
(B) Correct method (C) Incorrect method
• Make sure the terminal condition of the connectors
is not bent, rusty, and so on.
•
If the terminal is rusted, remove rust with
sandpaper.
However, do not polish the terminal of the
waterproof connector or the plated terminal.
GENERAL WORKING PRECAUTIONS
9. Handling fuses 2. GENERAL
05-E4B SERIES,05-E4BG SERIES
2-5
