Electrical system
Item Service specification Service limit
Glow plug Resistance
Approx.
0.9 Ω
－
Commutator (Starter)
Electromagnetic drive type
O.D.
28.0 mm
1.10 in.
27.0 mm
1.06 in.
Gear reduction type
O.D.
30.0 mm
1.18 in.
29.0 mm
1.14 in.
Mica (Starter)
Electromagnetic drive type
Undercut
0.50 to 0.80 mm
0.020 to 0.031 in.
0.20 mm
0.0079 in.
Gear reduction type
Undercut
0.50 to 0.80 mm
0.020 to 0.031 in.
0.20 mm
0.0079 in.
Brush (Starter)
Electromagnetic drive type
Length
16.0 mm
0.630 in.
10.5 mm
0.413 in.
Gear reduction type
Length
16.0 mm
0.630 in.
10.5 mm
0.413 in.
Stator coil (Alternator) Resistance
Less than
1.0 Ω
－
Rotor coil (Alternator) Resistance 2.9 Ω －
Slip ring (Alternator) O.D.
14.4 mm
0.567 in.
14.0 mm
0.551 in.
Brush (Alternator) Length
10.0 mm
0.394 in.
8.4 mm
0.33 in.
Holding coil (Alternator) Resistance
Approx.
16 Ω
－
Pulling coil (Alternator) Resistance
Approx.
0.38 Ω
－
SERVICING
2. Servicing specifications 4. ENGINE
05-E4B SERIES,05-E4BG SERIES
4-15
KiSC issued 03, 2023 A
