Kyocera TASKalfa 220 - System; Paper Feed Section

2KL/2KK
1-4-3
Section Description Conditions Specified time
System 00
No paper feed
The power is turned on when a sensor in the conveying
system is on.
-
The document processor is opened while originals fed
from the document processor are scanned.
-
04
Cover open
Cover is open during copying. -
05
Secondary paper feed
does not start
Secondary paper feed does not start within specified time
of arrival of paper at the registration section.
30 s
Paper
feed
section
10
No paper feed from MP
tray
The registration switch (RSW) does not turn on within the
specified time of paper MP solenoid (MPSOL) turning on
and cannot be detected at the same timing even after
retry.
1570 ms
11
No paper feed from
cassette
The registration switch (RSW) does not turn on within the
specified time of paper feed clutch 1 (PFCL1) turning on
and cannot be detected at the same timing even after
retry.
1327 ms
12
No paper feed from first
paper feeder
The registration switch (RSW) does not turn on within the
specified time of cassette paper feed clutch 1 (CPFCL1)
turning on and cannot be detected at the same timing
even after retry.
2290 ms
13
No paper feed from
second paper feeder
Cassette feed switch 1 (CFSW1) does not turn on within
the specified time of cassette paper feed clutch 2
(CPFCL2) turning on and cannot be detected at the same
timing even after retry.
1953 ms
14
No paper feed from
third paper feeder
Cassette feed switch 2 (CFSW2) does not turn on within
the specified time of cassette paper feed clutch 3
(CPFCL3) turning on and cannot be detected at the same
timing even after retry.
1953 ms
15
Misfeed in vertical
paper conveying sec-
tion 1
The registration switch (RSW) does not turn on within
specified time of cassette feed switch 1 (CFSW1) turning
on.
2243 ms
Cassette feed switch 1 (CFSW1) does not turn off within
specified time of cassette feed switch 2 (CFSW2) turning
on.
1916 ms
Cassette feed switch 1 (CFSW1) does not turn off within
specified time of cassette feed switch 2 (CFSW2) turning
off.
1916 ms
Left cover is opened in prior to the cassette feed switch 1
(CFSW1) is turned off.
-
16
Misfeed in vertical
paper conveying sec-
tion 2
Cassette feed switch 1 (CFSW1) does not turn on within
specified time of cassette feed switch 2 (CFSW2) turning
on.
1916 ms
Left cover is opened in prior to the cassette feed switch 2
(CFSW2) is turned off.
-
20
Multiple sheets in MP
tray
The registration switch (RSW) does not turn off within
specified time of its turning on.
5907 ms
The registration switch (RSW) does not turn off within the
specified time of paper MP solenoid (MPSOL) turning on.
1570 ms
