Kyocera TASKalfa 220 - Duplex Section; Document Processor

2KL/2KK
1-4-6
Feedshift
section
56
Misfeed in feedshift
section (third paper
feeder)
The job eject switch (JBESW) does not turn on within
specified time of the feedshift switch (FSSW) turning on.
2056 ms
The feedshift switch (FSSW) does not turn on within
specified time of paper switchback operation.
1364 ms
The feedshift switch (FSSW) does not turn off within
specified time of the registration clutch (RCL) turning on.
2766 ms
The feedshift switch (FSSW) does not turn off within
specified time of the its turning on.
5907 ms
57
Misfeed in feedshift
section (duplex section)
The job eject switch (JBESW) does not turn on within
specified time of the feedshift switch (FSSW) turning on.
2056 ms
The feedshift switch (FSSW) does not turn on within
specified time of paper switchback operation.
1364 ms
The feedshift switch (FSSW) does not turn off within
specified time of the registration clutch (RCL) turning on.
2766 ms
The feedshift switch (FSSW) does not turn off within
specified time of the its turning on.
5907 ms
Duplex
section
60
Misfeed in duplex
paper conveying sec-
tion
The duplex paper conveying switch (DUPPCSW) does
not turn off within specified time of the feedshift switch
(FSSW) turning on.
3037 ms
The duplex paper conveying switch (DUPPCSW) does
not turn on within specified time of the feedshift switch
(FSSW) turning on.
3037 ms
The duplex paper conveying switch (DUPPCSW) does
not turn off within specified time of the feedshift switch
(FSSW) turning off.
3037 ms
61
Misfeed in duplex eject
section
The registration switch (RSW) does not turn on within
specified time of the duplex paper conveying switch
(DUPPCSW) turning on.
1589 ms
The registration switch (RSW) does not turn off within
specified time of the duplex paper conveying switch
(DUPPCSW) turning off.
1589 ms
Document
processor
70
No original feed
During primary feed of the second original in the simplex
or duplex mode, even if retry operation is performed five
times, primary original feed is not performed.
-
71
An original jam in the
original conveying sec-
tion 1
During the secondary original feed in the simplex mode,
DP timing switch (DPTSW) does not turn off within speci-
fied time of the original conveying motor (OCM) turning
on.
9900 pulses
72
An original size error
jam
DP timing switch (DPTSW) turns off within the specified
time of period of the original conveying motor (OCM)
turning on in the simplex or duplex mode.
1145 pulses
73
An original jam in the
original conveying sec-
tion 2
During original conveying in the duplex mode, DP timing
switch (DPTSW) does not turn off within specified time of
the original conveying motor (OCM) turning on.
9900 pulses
74
An original jam in the
original conveying sec-
tion 3
During secondary original feed in the duplex mode, DP
timing switch (DPTSW) does not turn on within specified
time of the original switchback motor (OSBM) turning on.
2300 pulses
Section Description Conditions Specified time
