2KL/2KK
1-3-22
U068
Adjusting the scanning position for originals from the DP
Description
Adjusts the position for scanning originals from the DP.
Purpose
Used when the image fogging occurs because the scanning position is not proper when the DP is used. Run
U071 to adjust the timing of DP leading edge when the scanning position is changed.
Setting
1. Press the start key.
2. Change the setting using the zoom +/- keys.
Increasing the value moves the image backward, and decreasing it moves the image forward.
Supplement
While this maintenance item is being executed, copying from an original is available in interrupt copying mode
(which is activated by pressing the interrupt key).
Completion
Press the stop/clear key. The screen for selecting a maintenance item No. is displayed.
Maintenance
item No.
Description
Description Setting range Initial setting Change in value per step
Scanning position -17 to 17 0 0.17 mm
