Kyocera TASKalfa 2550ci - Page 471

2MV
2-3-36
YC14
13.3V5 O
3.3 V DC 3.3 V DC power output to ODSW
Connected to
original
detection
switch
2GND -
- Ground
3CO_SW I
0/3.3 V DC ODSW: On/Off
Connector Pin Signal I/O Voltage Description
