2KR/2KS
1-3-72
U247
Setting the paper feed device
Description
Turns on motors and clutches of 3000-sheet paper feeder or paper feeder.
Purpose
To check the operation of motors and clutches of paper feed device.
Method
1. Press the start key. The value varies depending to the option furnished.
2. Select the item to be operated.
3. Press the start key. The operation starts.
3000-sheet paper feeder.
Paper feeder
4. To turn each motor off, press the stop key.
Completion
Press the stop key. The screen for selecting a maintenance item No. is displayed.
Maintenance
item No.
Description
Display Motor and clutches Operation
LCF FEED PF conveying motor (PFCM) In operation
CLUTCH B PF conveying clutch (PFCCL) On for 1 s
CLUTCH P1 PF paper feed clutch 1 (PFPFCL1) On for 1 s
CLUTCH P2 PF paper feed clutch 2 (PFPFCL2) On for 1 s
Display Motor and clutches Operation
DESK FEED PF drive motor (PFDM) In operation
CLUTCH FEED PF feed clutch (PFFCL) On for 1 s
CLUTCH U PF paper feed clutch 1 (PFPFCL1) On for 1 s
CLUTCH L PF paper feed clutch 2 (PFPFCL2) On for 1 s
