2KR/2KS-1
2-4-1
2-4 Appendixes
Maintenance parts list
Maintenance part name
Part No.
Alternative part
No.
Name used in service manual Name used in parts list
Paper feed pulley PULLEY,PAPER FEED 2AR07220 -
Separation pulley PULLEY,SEPARATION 2AR07230 -
Forwarding pulley PULLEY FEED A 2BJ06010 -
MP paper feed pulley UPPER PULLEY,BYPASS 61706770 -
MP separation pulley PULLEY,SEPARATION 2AR07230 -
MP forwarding pulley PULLEY FEED A 2BJ06010 -
MP feed roller 1 PARTS ROLLER2 BYPASSFEED SP 302KS94160 2KS94160
MP feed roller 2 PARTS ROLLER4 BYPASSFEED SP 302KS94170 2KS94170
MP feed pulley RIGHT PULLEY,FEED 33906660 -
Left registration roller UPPER ROLLER REGIST 302KS06010 2KS06010
Right registration roller RIGHT ROLLER REGIST 302FG06211 2FG06211
Feed pulley PULLEY FEED 2BL16080 -
Feed roller 1 PULLEY MIDDLE FEED A 302GR06010 2GR06010
Feed roller 1 PULLEY MIDDLE FEED B 302GR06020 2GR06020
Feed roller 2 PARTS ROLLER B FEED SP 302KS94140 2KS94140
Feed roller 3 PARTS ROLLER C FEED SP 302KS94150 2KS94150
Registration switch SWITCH REGISTRATION 2FG27110 -
Left registration cleaner UNDER CLEANER REGIST 2BL07950 -
Registration guide GUIDE REGIST F 2BL16130 -
Right registration cleaner PARTS,REGISTRATION CLEAN 2BL93450 -
Transfer guide PARTS,GUIDE TRANSFER 302GR94480 2GR94480
Laser scanner unit PARTS LSU 302KS93040 2KS93040
Slit glass PARTS CONTACT GLASS ADF ASSY 302H793480 2H793480
Contact glass PARTS CONTACT GLASS (M) ASSY SP 302KS94250 2KS94250
PARTS CONTACT GLASS (I) ASSY SP 302KS94260 2KS94260
Mirror 1 MIRROR A 2FB12140 -
Mirror 2 and mirror 3 MIRROR B 2FB12180 -
Lens - - -
Reflector REFRECTOR SCANNER 302GR17250 2GR17250
Exposure lamp PARTS LAMP SCANNER 302H794260 2H794260
Optical rail F - - -
Optical rail R - - -
Original size sensor SENSOR ORIGINAL 2C927090 -
Transfer roller unit TR-710 302GR93281 2GR93281
Developing unit DV-715 302GR93034 2GR93034
Drum unit DK-716 302GR93042 2GR93042
Main charger unit MC-710 302GR93071 2GR93071
Drum separation claw PARTS CLAW SEPARATION ASSY 302GR93190 2GR93190
Fuser unit PARTS FUSER 120 UNIT 302KS93010 2KS93010
Fuser unit PARTS FUSER 230 UNIT 302KS93020 2KS93020
Heat roller PARTS,ROLLER HEAT SP 302GR94270 2GR94270
Heat roller separation claw CLAW HEAT ROLLER 2BL20080 -
Press roller PARTS,ROLLER PRESS SP 302GR94280 2GR94280
Press roller separation claw CLAW PRESS ROLLER 302BL20351 2BL20351
