2KR/2KS
1-3-104
U942
Setting of deflection for feeding from DP
Description
Adjusts the deflection generated when the DP is used.
Purpose
Use this mode if an original non-feed jam, oblique feed or wrinkling of original occurs when the DP is used.
Setting
1. Press the start key.
2. Select the item to be adjusted.
3. Press the system menu key.
4. Place an original on the DP and press the start key to make a test copy.
5. Press the system menu key.
6. Change the setting value using the +/- or numeric keys.
The greater the value, the larger the deflection; the smaller the value, the smaller the deflection.
If an original non-feed jam or oblique feed occurs, increase the setting value. If wrinkling of original
occurs, decrease the value.
7. Press the start key. The setting is set.
Completion
Press the stop key. The screen for selecting a maintenance item No. is displayed.
U964
Checking of log
Description
Sends a log file saved on the HDD to a USB memory.
Purpose
To transfer a log file saved on the HDD to a USB memory as a means of investigating malfunctions.
Method
1. Insert USB memory in USB memory slot.
2. Turn the main power switch on.
3. Enter the maintenance item.
4. Press the start key.
5. Select [Execute].
6. Press the start key.
Starts sending the log file saved on the HDD to the USB memory.
7. When normally completed, [Finished] is displayed.
When an error occurs, an error code is displayed.
8. Turn the main power switch off and on.
Error codes
Maintenance
item No.
Description
Display Description Setting Initial Change in
REGIST TOP Deflection of single-sided original -31 to 31 0 0.18 mm
REGIST BACK Deflection of double-sided original -31 to 31 0 0.18 mm
REGIST MIX Deflection of dual scanning -31 to 31 0 0.18 mm
Display Description
No Usb Storage USB memory is not inserted
No File
File is not found
Mount Error USB memory mount error
File Delete Error File deletion error
Copy Error File copy error
Unmount Error USB memory unmount error
Other Error Other error
