Kyocera TASKalfa 420i - Machine Rear

2KR/2KS
1-5-44
Figure 1-5-85Machine rear
Intake
Intake
Exhaust
Controller fan motor
(Rating label: inside)
Scanner fan motor
(Rating label: inside)
Fuser fan motor
(Rating label: outside)
Power source
fan motor 1
(Rating label: inside)
Power source
fan motor 2
(Rating label: upside)
