LeeBoy 8510E - Joystick Control Box

JOYSTICK CONTROL BOX
Schematic for Part # 1016272SRV
Figure 6-9. Joystick Control Box
3
2
FWD
REV
4 OUTPUT
5 GND
3 +5 VDC
2 NEUTRAL N.C.
3 NEUTRAL N.O.
"B"
"B"
1 NEUTRAL N.C.
3 NEUTRAL COM
2 NEUTRAL N.O.
3 +5 VDC
5 GND
4 OUTPUT
REV
FWD
1 NEUTRAL COM
LEFT JOYSTICK
RIGHT JOYSTICK
RUN/STOP
J
D
B
C
G
F
LEFT
FORWARD
LEFT
REVERSE
RIGHT
FORWARD
RIGHT
REVERSE
RUN STOP
986539
N N
1016272 - DUAL JOYSTICK CONTROL BOX
986539 - DUAL JOYSTICK DECAL
LeeBoy 8510E Conveyor Paver 6-19
