HYDRAULIC HOSE SCHEDULE
Hose
No.
Qty. Part Number Description
1 1018948 Main Hose Kit
1A 1 K811HTJCJC161616-72-SG-155-69.5 HOSE ASSEMBLY, HYDRAULIC, SUCTION, -16FFSS/-16FFSS, 72"
2A 1 F387TCJCJ5080808-118-SG-084-115.75 HOSE ASSEMBLY, HYDRAULIC, 3000 PSI, -8FFSS/-8FFS90M, 118"
2B 1 F387TCJCJ5080808-118-SG-084-115.75 HOSE ASSEMBLY, HYDRAULIC, 3000 PSI, -8FFSS/-8FFS90M, 118"
5 1 F387TCJCJ9101010-91-SG-097-88.5 HOSE ASSEMBLY, HYDRAULIC, 3000 PSI, -10FFSS/-10FFS90S, 91"
7 1 K811HTJCJ9161616-37-SG-155-33.75 HOSE ASSEMBLY, HYDRAULIC, SUCTION, -16FFSS/-16FFS90S, 37"
8 1 F387TCJCJ9101010-50-SG-097-47.5 HOSE ASSEMBLY, HYDRAULIC, 3000 PSI, -10FFSS/-10FFS90S, 50"
10 1 F387TCJCJ9060606-110 HOSE ASSEMBLY, HYDRAULIC, 3000 PSI, -6FFSS/-6FFS90S, 110"
11 1 F387TCJCJ1060606-103 HOSE ASSEMBLY, HYDRAULIC, 3000 PSI, -6FFSS/-6FFS90L, 103"
12 1 F387TCJCJC060606-39.5 HOSE ASSEMBLY, HYDRAULIC, 3000 PSI, -6FFSS/-6FFSS, 39.5"
13 1 F387TCJCJC060606-33 HOSE ASSEMBLY, HYDRAULIC, 3000 PSI, -6FFSS/-6FFSS, 33"
15 1 F387TCJCJ7101010-60 HOSE ASSEMBLY, HYDRAULIC, 3000 PSI, -10FFSS/-10FFS45, 60"
16A 1 F387TCJCJ9080808-40.5-AS-B-15-38.25 HOSE ASSEMBLY, HYDRAULIC, 3000 PSI, -8FFSS/-8FFS90S, 40.5"
16B 1 F387TCJCJ9080808-39-AS-B-15-36.75 HOSE ASSEMBLY, HYDRAULIC, 3000 PSI, -8FFSS/-8FFS90S, 39"
17A 1 F387TCJCJ1080808-52.5-AS-B-15-50.25 HOSE ASSEMBLY, HYDRAULIC, 3000 PSI, -8FFSS/-8FFS90L, 52.5"
17B 1 F387TCJCJ1080808-52.5-AS-B-15-50.25 HOSE ASSEMBLY, HYDRAULIC, 3000 PSI, -8FFSS/-8FFS90L, 52.5"
20 1 K811HTJCJC242424-136-AS-B-37-132.25 HOSE ASSEMBLY, HYDRAULIC, SUCTION, -24FFSS/-24FFSS, 136"
25 1 F387TCJCJ7060606-27 HOSE ASSEMBLY, HYDRAULIC, 3000 PSI, -6FFSS/-6FFS45, 27"
28 1 F387TCJCJC060606-182 HOSE ASSEMBLY, HYDRAULIC, 3000 PSI, -6FFSS/-6FFSS, 182"
29 1 F387TCJCJC040404-171 HOSE ASSEMBLY, HYDRAULIC, 3000 PSI, -4FFSS/-4FFSS, 171"
30 1 F487STJCJ5121212-169.5 HOSE ASSEMBLY, HYDRAULIC, 4000 PSI, -12FFSS/-12FFS90M, 169.5"
31 1 F487STJCJ5121212-168.5 HOSE ASSEMBLY, HYDRAULIC, 4000 PSI, -12FFSS/-12FFS90M, 168.5"
32 1 F487STJCJ5121212-174 HOSE ASSEMBLY, HYDRAULIC, 4000 PSI, -12FFSS/-12FFS90M, 174"
33 1 F487STJCJ5121212-177.5 HOSE ASSEMBLY, HYDRAULIC, 4000 PSI, -12FFSS/-12FFS90M, 177.5"
34 1 F387TCJCJ9101010-40-SG-097-37.5 HOSE ASSEMBLY, HYDRAULIC, 3000 PSI, -10FFSS/-10FFS90S, 40"
35 1 F387TCJCJ9121212-32.5 HOSE ASSEMBLY, HYDRAULIC, 3000 PSI, -12FFSS/-12FFS90S, 32.5"
36 1 F387TCJCJ5121212-85-SG-113-81.75 HOSE ASSEMBLY, HYDRAULIC, 3000 PSI, -12FFSS/-12FFS90M, 85"
38 1 F387TCJCJ7121212-76-AS-B-19-72.75 HOSE ASSEMBLY, HYDRAULIC, 3000 PSI, -12FFSS/-12FFS45, 76"
39 1 F387TCJCJ5080808-17.5 HOSE ASSEMBLY, HYDRAULIC, 3000 PSI, -8FFSS/-8FFS90M, 17.5"
40 1 F387TCJCJ5080808-17.5 HOSE ASSEMBLY, HYDRAULIC, 3000 PSI, -8FFSS/-8FFS90M, 17.5"
41 1 F387TCJCJ5040404-48.5 HOSE ASSEMBLY, HYDRAULIC, 3000 PSI, -4FFSS/-4FFS90M, 48.5"
42 1 F387TCJCJ7060606-68 HOSE ASSEMBLY, HYDRAULIC, 3000 PSI, -6FFSS/-6FFS45, 68"
43 1
F387TCJCJC060606-109 HOSE ASSEMBLY, HYDRAULIC, 3000 PSI, -6FFSS/-6FFSS, 109"
44 1 F387TCJCJC060606-109 HOSE ASSEMBLY, HYDRAULIC, 3000 PSI, -6FFSS/-6FFSS, 109"
45 1 F387TCJCJC060606-68 HOSE ASSEMBLY, HYDRAULIC, 3000 PSI, -6FFSS/-6FFSS, 68"
51 1 F387TCJCJC060606-164 HOSE ASSEMBLY, HYDRAULIC, 3000 PSI, -6FFSS/-6FFSS, 164"
54 1 F387TCJCJ9080808-14.5 HOSE ASSEMBLY, HYDRAULIC, 3000 PSI, -8FFSS/-8FFS90S, 14.5"
62 1 K811HTJCJ7161616-178 HOSE ASSEMBLY, HYDRAULIC, SUCTION, -16FFSS/-16FFS45, 178"
71 1 F387TCJCJ9121212-223.5-AS-B-19-220.25 HOSE ASSEMBLY, HYDRAULIC, 3000 PSI, -12FFSS/-12FFS90S, 223.5"
74 1 F387TCJCJC040404-169 HOSE ASSEMBLY, HYDRAULIC, 3000 PSI, -4FFSS/-4FFSS, 169"
Illustrated Parts List
LeeBoy 8510E Conveyor Paver7-178
