LeeBoy 8510E - Option - HD 3:1 Depth Screws (2 of 2)

Item
No
Part Number Qty Description Remarks
36 20160644 6 Spirol Pin, ø3/8 x 1.750 (3) Per Assembly
37 113-6-16-6 2 Set Screw, HSKT, Cup, 3/8-16 x .375 (1) Per Assembly
38 1014927 2 Planetary Box Coupler (1) Per Assembly
39 20931333 2 Tongued Washer, 1.21 ID x 1.86 OD (1) Per Assembly
40 95200978 2 Lockwasher (1) Per Assembly
41 95200879 2 Locknut (1) Per Assembly
42 1014926 2 Lower Planetary Drive Shaft (1) Per Assembly
43 21426507 2 Universal Joint (1) Per Assembly
REF 20960332 A/R Universal Joint Bearing As Needed
44 1006431 2 Adjuster Screw (1) Per Assembly
45 1006429 2 Adjuster Sleeve w/Ball Joint (1) Per Assembly
46 100-12-10-36-5 2 CSHH, 3/4-10 x 2.25, GR5 (1) Per Assembly
47 302-12 2 Washer, Lock, 3/4 (1) Per Assembly
Option - HD 3:1 Depth Screws (2 of 2)
7
Illustrated Parts List
LeeBoy 8510E Conveyor Paver 7-155
