QUICK REFERENCE
FILTERS/STRAINERS
Engine Description Part #
Oil Filter 986537-03
Water Separator 1009253-19
Fuel Filter 1009253-18
Air Cleaner, Primary 1009253-17
Air Cleaner, Secondary 1009253-16
Hydraulic
Suction Strainer, 1-7/8-12 SAE 1011817
Suction Strainer, 2-1/2-12 SAE 1014037
Charge Filter 290030
Charge/Return Filter Head 1017402
Spray Down
Pump and Strainer Kit 1015532
Filter 986537-31
ENGINE COMPONENTS
Description Part #
Engine Belt 1009253-20
Alternator 1009253-21
Starter 1001166-03
ELECTRICAL COMPONENTS
Description Part #
FUSE KIT:
• 5A ATC
• 10A ATC
• 15A ATC
• 20A ATC
• 25A ATC
36746
36340
36341
36342
37303
FUSE KIT
• 5A ATM
• 20A ATM
• 30A ATM
1017776-05
1017776-20
1017776-30
Fuse Block, ATC 685060
Breaker, 10A 986546
TRACK ASSEMBLIES
Description Part #
Track Assembly w/Poly Pads 851101P
Track Assembly w/Cast Pads 851101
Continuous Rubber Track 982585
WEAR PLATES
LEGEND LP Screed
Main Screed Wear Plate 981724SRV
Extension Heat Box Assy (LH/RH) 851182SRV
LEGEND Electric Screed
Main Screed Wear Plate 987216SRV
Extension Heat Box Assy (LH/RH) 987872SRV
HD Screed
HD Main Screed, 3/8” w/ Studs 1016475
HD Ext. Heat Box Assy (LH/RH) 1006380SRV
Berm Ext. Main Heat Box Assy (LH) 1017683SRV
Berm Ext. Main Heat Box Assy (RH) 1017682SRV
HEATING ELEMENTS
LEGEND Electric Screed
Legend Main Heating Element (2) 987886SRV
Legend Extension HE (2) 987890SRV
HD Screed
HD Main Heating Element (2) 1015855SRV
HD Ext Heating Element (2) 1007278SRV
Berm Main Ext. HE (2) 1015936
Berm Ext. Heating Element (2) 1015918
