LeeBoy 8510E - Option - Topcon P-32 Control Assembly (2 of 2)

Option - TopCon P-32 Control Assembly (2 of 2)
Item
No
Part Number Qty Description Remarks
9 300-12 1 Washer, Flat, SAE, 3/4
10 985866 1 AM Module & Cable Assembly Includes Items 11, 12
15 1010499-06 1 Sonic Tracker II Assembly
16 1010499-07 1 Temp Bail w/Sleeves Assembly
17 1010499-04 1 GC-35/Sonic Tracker Cord Assembly (15 ft.)
18 1010499-03 1 Carrying Case
19 1010499-01 1 GC-35 Quick Reference Guide Not Shown
20 1010499-05 2 GC-35 Paver Bracket Assembly
REF 1010499-02 1 Sonic Tracker Bracket Assembly w/L-Bolt
REF 987338SRV 1 Option - Wiring, TopCon Grade Control Not Shown
7
Illustrated Parts List
LeeBoy 8510E Conveyor Paver 7-173
