LeeBoy 8510E - Drive Assembly - Continuous Rubber (1 of 2); Drive Assembly - Continuous Rubber (2 of 2)

Drive Assembly - Continuous Rubber (2 of 2)
Item
No
Part Number Qty Description Remarks
34
FS6802-04-04-NWO-FG
2 Elbow Adapter, 45°, -4 ORFS/ -4 O-Ring
35
FS2700-12-12 4 Bulkhead Union Adapter, -12 ORFS / -12 ORFS
36
FS0306-12 5 Bulkhead Lock Nut, -12 ORFS
37 FS2704-04-04-04-FG
1 Run Tee Bulkhead Adapter, -04 ORFS (x3)
38
FS0306-04 1 Bulkhead Lock Nut, -4 ORFS
39
FS2704-12-12-12-FG 1 Run Tee Bulkhead Adapter, -12 ORFS (x3)
40
FS2406-12-10 3 Straight Reducer Adapter, -12 FFORX/-10 ORFS
41
FS6500-12-12-FG 1 Swivel Elbow Adapter, 90°, -12 ORFS/-12 ORFS
42
FS6602-12-12-12-FG 1 Swivel Run Tee Adapter, -12 ORFS (x3)
7
Illustrated Parts List
LeeBoy 8510E Conveyor Paver 7-13
