LeeBoy 8510E - Page 385

Hose
No.
Qty. Part Number Description
1 1016854 Drive Motor Hose Kit
30 1 F487ST0639121212-48 LH DRIVE FRONT PORT TO LH LOWER BULKHEAD
31 1 F487ST0639121212-47 LH DRIVE REAR PORT TO LH UPPER BULKHEAD
32 1 F487ST0639121212-27 RH DRIVE FRON T PORT RH LOWER BULKHEAD
33 1 F487ST0639121212-28.5 RH DRIVE REAR PORT TO RH TOP BULKHEAD
67 1 F387TC0639101010-52 LH CASE DRAIN TO BULKHEAD TEE
68 1 F387TC0606101010-30.5 RH CASE DRAIN TO BULKHEAD TEE
69 1 F387TC0606040404-38 RH BRAKE TO BULKHEAD TEE
70 1 F387TC0641040404-40.25 RH TWO SPEED TO TEE
72 1 F387TC0606040404-14.25 LH TWO SPEED TO TEE
73 1 F387TC0639040404-55 LH BRAKE TO BULKHEAD TEE
Hose
No.
Qty. Part Number Description
1 1016860 Track Tension Hose Kit
75 F387TC0639080808-42.5 TT MANIFOLD TO RH CYLINDER
76 F387TC0639080808-26 TT MANIFOLD TO LH CYLINDER
Hose
No.
Qty. Part Number Description
1 1018968 Electric Heat Hose Kit
4 1 F387TCJCJ5101010-14 HOSE ASSEMBLY, HYDRAULIC, 3000 PSI, -10FFSS/-10FFS90M, 14"
1B 1 K811HTJCJ9161616-70-SG-155-67.5 UPPER TANK TO GENERATOR PUMP (SUCTION)
55 1 F787TCJCJ1080808-201 GEN MANIFOLD GEN PORT TO GEN MOTOR REAR
56 1 F387TCJCJ9060606-21.5 GEN CASE DRAIN TO BOTTOM TANK
57 1 F387TCJCJ5101010-25 GEN RETURN TO BULKHEAD TEE
Hose
No.
Qty. Part Number Description
1 1015125 816 Main Screed Hose Kit
84/85 2 F387TC0606060606-27-AS-B-13-24 HOSE ASSEMBLY, HYDRAULIC, 3000 PSI, -6FJX/-6FJX, 27"
86/87 2 F387TC0606060606-80-AS-B-13-77 HOSE ASSEMBLY, HYDRAULIC, 3000 PSI, -6FJX/-6FJX, 80"
Hose
No.
Qty. Part Number Description
1 1015125 Screed Bern Grease Line Hose Kit
1 2 F387TC0101040404-20 HOSE ASSEMBLY, HYDRAULIC, 3000 PSI, -4MP/-4MP, 20"
Hose
No.
Qty. Part Number Description
1 1015859 Screed Hose Kit
80 1 F387TC0639060606-72 HOSE ASSEMBLY, HYDRAULIC, 3000 PSI, -6FJX/-6FJX90S, 72"
81 1 F387TC0639060606-72 HOSE ASSEMBLY, HYDRAULIC, 3000 PSI, -6FJX/-6FJX90S, 72"
82 1 F387TC0641060606-72 HOSE ASSEMBLY, HYDRAULIC, 3000 PSI, -6FJX/-6FJX90L, 72"
83 1 F387TC0641060606-72 HOSE ASSEMBLY, HYDRAULIC, 3000 PSI, -6FJX/-6FJX90L, 72"
7
Illustrated Parts List
LeeBoy 8510E Conveyor Paver 7-179
