LeeBoy 8510E - Page 386

Hose
No.
Qty. Part Number Description
1 1019390 High Deck 7 Section Valve Hose Kit
18 1 F387TCJCJ7101010-100 7 SECTION OUT PORT TO TOP ENGINE COOLER TEE
19 1 F387TCJCJ5101010-60.25 7 SECTION PRESSURE IN PORT TO LOWER MANIFOLD CM PORT
21 1 F387TCJCJC080808-56 7 SECTION RELIEF PORT TO TANK TEE
22 1 F387TCJCJC060606-242 7 SECTION REAR A PORT TO RH CUTOFF CYLINDER BASE END
23 1 F387TCJCJC060606-251 7 SECTION FRONT B PORT TO RH CUTOFF CYLINDER ROD END
24 1 F387TCJCJC060606-217 7 SECTION REAR A PORT TO CONVEYOR LIFT CYLINDER BASE END
26 1 F387TCJCJC060606-222 7 SECTION REAR A PORT TO LH CUTOFF CYLINDER BASE END
27 1 F387TCJCJC060606-227 7 SECTION FRONT B PORT TO LH CUTOFF CYLINDER ROD END
14A 1 F387TCJCJC060606-73.75 7 SECTION FRONT B PORT TO SIDEWING MANIFOLD A PORT
14B 1 F387TCJCJC060606-72.5 7 SECTION REAR A PORT TO SIDEWING MANIFOLD B PORT
46 1 F387TCJCJC060606-50.5 7 SECTION REAR A PORT TO LOWER MANIFOLD SR PORT
47 1 F387TCJCJC060606-50.5 7 SECTION FRONT B PORT TO LOWER MANIFOLD SL PORT
80 1 F387TCJCJ9060606-87 7 SECTION FRONT B PORT TO BOTTOM LEFT BULKHEAD
81 1 F387TCJCJ9060606-87 7 SECTION FRONT B PORT TO BOTTOM RIGHT BULKHEAD
82 1 F387TCJCJ1060606-87 7 SECTION REAR A PORT TO TOP LEFT BULKHEAD
83 1 F387TCJCJ1060606-87 7 SECTION REAR A PORT TO TOP RIGHT BULKHEAD
Hose
No.
Qty. Part Number Description
1 1018994 Low Deck 7 Section Valve Hose Kit
18 1 F387TCJCJ7101010-87 7 SECTION OUT PORT TO TOP ENGINE COOLER TEE
19 1 F387TCJCJ5101010-55 7 SECTION PRESSURE IN PORT TO LOWER MANIFOLD CM PORT
21 1 F387TCJCJC080808-45 7 SECTION RELIEF PORT TO TANK TEE
22 1 F387TCJCJC060606-234 7 SECTION REAR A PORT TO RH CUTOFF CYLINDER BASE END
23 1 F387TCJCJC060606-236 7 SECTION FRONT B PORT TO RH CUTOFF CYLINDER ROD END
24 1 F387TCJCJC060606-199 7 SECTION REAR A PORT TO CONVEYOR LIFT CYLINDER BASE END
26 1 F387TCJCJC060606-211 7 SECTION REAR A PORT TO LH CUTOFF CYLINDER BASE END
27 1 F387TCJCJC060606-213 7 SECTION FRONT B PORT TO LH CUTOFF CYLINDER ROD END
14A 1 F387TCJCJC060606-62.5 7 SECTION FRONT B PORT TO SIDEWING MANIFOLD A PORT
14B 1 F387TCJCJC060606-62.5 7 SECTION REAR A PORT TO SIDEWING MANIFOLD B PORT
46 1 F387TCJCJC060606-32.5 7 SECTION REAR A PORT TO LOWER MANIFOLD SR PORT
47 1 F387TCJCJC060606-32.5 7 SECTION FRONT B PORT TO LOWER MANIFOLD SL PORT
80 1 F387TCJCJ9060606-72 7 SECTION FRONT B PORT TO BOTTOM LEFT BULKHEAD
81 1 F387TCJCJ9060606-72 7 SECTION FRONT B PORT TO BOTTOM RIGHT BULKHEAD
82 1 F387TCJCJ1060606-72 7 SECTION REAR A PORT TO TOP LEFT BULKHEAD
83 1 F387TCJCJ1060606-72 7 SECTION REAR A PORT TO TOP RIGHT BULKHEAD
Illustrated Parts List
LeeBoy 8510E Conveyor Paver7-180
