LeeBoy 8510E - Page 229

Conveyor Drive & Paddle Assembly (2 of 2)
Item
No
Part Number Qty Description Remarks
37 900050SRV 2 Conveyor Automatic Micro Switch
38 1016524SRV 1 Conveyor Cutoff Assembly - Right Includes 16,32-33,39-41
39 1016525 1 Conveyor Cutoff Hinge Weldment - Right
40 1016526 1 Conveyor Cutoff Flap Weldment - Right
41 1015298 1 Conveyor Flap Hinge Pin - Right
42 100-8-13-16-5F 4 CSHH, 1/2-13 x 1.00, GR5, FT
43 302-8 4 Washer, Lock, 1/2
44 300-8 4 Washer, Flat, SAE, 1/2
7
Illustrated Parts List
LeeBoy 8510E Conveyor Paver 7-23
