LeeBoy 8510E - Page 235

Item
No
Part Number Qty Description Remarks
32R 1019052 1 Auger Assembly w/Mount, 12" - Right
Includes Items 29,33-38,39R,40-46
33 1007270 2 Shaft w/Sprocket, 12" Auger Includes Items 34,35
34 1007323 2 Auger Bearing Spacer Washer
35 1007267 2 Auger Bearing
36 1007306 2 Auger Shaft Spacer Assembly
37 100-10-11-44-5 8 CSHH, 5/8-11 x 1.75, GR5
38 200-10-11-5 8 Nut, Hex, 5/8-11, GR5
39L 981700L 4 Auger Flight, 12" - Left
39R 981700R 4 Auger Flight, 12" - Right
40 310-24 4 Washer, Hardened, SAE, 1-1/2"
REF 1019053 2 Auger End Mount Assembly - Long Includes Items 41-45
41 851645 2 Auger Shaft Collar
42 1017379 4 Set Screw, 3/8-16 x .75, Knurl Cup Point
43 810070 2 Bushing, 2.00 ID x 2.50 OD x 2.50
44 1019053-01 2 Auger End Mount - Long
45 29A-02 2 Grease Fitting, 1/8 NPT Straight
46 1019051-01 2 Auger Spacer Tube
47 100-8-13-24-5 4 CSHH, 1/2-13 x 1.50, GR5
48 102-6-16-40 2 CSSH, 3/8-16 x 2.50
49 202-6-16-5 2 Nut, Hex, Jam, 3/8-16, GR5
50 1008949 2 Grease Fitting, 1/4-28, Long
51 400-3-36 2 Roll Pin, 3/16 x 2.25
52 981688SRV 1 Chain Cover
53 100-6-16-16-5F 2 CSHH, 3/8-16 x 1.00, GR5, FT
54 302-6 2 Washer, Lock, 3/8
55 300-6 2 Washer, Flat, SAE, 3/8
56 100-8-20-16-5F 8 CSHH, 1/2-20 x 1.00, GR5, FT
57 1016721 1 Auger Back Wear Plate, 12"
Rear Auger Assembly (2 of 2)
7
Illustrated Parts List
LeeBoy 8510E Conveyor Paver 7-29
