Hydraulic Test Ports
Item
No
Part Number Qty Description Remarks
1 1018622 1 Test Port Plate
2 1019707 5 Hydraulic Test Port to #4 JIC Bulkhead
3 1017186 1 Decal - Test Port Label
4 100-5-18-12-5F 4 CSHH, 5/16-18 x .75, GR5, FT
5 302-5 4 Washer, Lock, 5/16
6 300-5 4 Washer, Flat, SAE, 5/16
REF 1013588-48 3 SMS Test Hose Assembly w/#4 Female JIC-48" Not Shown
REF 1013588-96 2 SMS Test Hose Assembly w/#4 Female JIC-96" Not Shown
7 1013595 1 Hydraulic Pressure Test Kit OPTION
7
Illustrated Parts List
LeeBoy 8510E Conveyor Paver 7-39
